When applications demand cables that can bend, flex, and withstand harsh environments—whether powering portable tools, feeding industrial machinery, or supplying mobile equipment—you need a rubber insulated flexible cable supplier whose products and services are engineered for reliability, performance, and longevity. Our company brings over 30 years of specialized expertise in formulating, extruding, and testing rubber‑based cable solutions. From bespoke compounds to turnkey assemblies, we deliver the ultimate rubber insulated flexible cable experience.
Inferior cable designs cut costs today but drive up expenses tomorrow through:
Mechanical Failures: Low‑grade jackets crack under repeated flex, allowing moisture ingress and conductor fatigue.
Safety Risks: Non‑flame‑retardant compounds ignite easily, while halogen‑rich sheaths emit toxic smoke.
Unplanned Downtime: Abraded or brittle cables seize reels, stall equipment, and require emergency swaps.
Hidden Lifecycle Costs: Frequent replacements, safety incidents, and labor delays erode your ROI.
As your dedicated rubber insulated flexible cable partner, we mitigate these risks by integrating:
Premium Elastomeric Formulations
Natural Rubber (Type YZ/YC) for exceptional low‑temperature flexibility.
Chloroprene (Type YZW/YCW) and EPR/EPRM for oil, chemical, UV, and ozone resistance.
Fine‑Strand Conductor Technology
Class 5 & Class 6 Copper Stranding per IEC 60228 for tight‑bend performance on reels and cable chains.
Tinned‑Copper Variants for marine, offshore, and high‑humidity environments.
Rigorous Testing & Certification
100% continuity, insulation‑resistance, high‑pot (AC withstanding), and tensile tests on every drum.
Compliance with UL 62/SOOW, IEC 60332, BS EN 50525, VDE, and CPR/EN 50575 fire standards.
By controlling every step—from compounding to final QC—our rubber insulated flexible cable solutions deliver unmatched durability and safety.
| Feature | Benefit |
|---|---|
| Voltage Rating: 300/500 V – 1 kV | Powers portable tools, welding leads, and heavy‑duty industrial feeds |
| Jacket Compounds: NR, CR, EPR, TPE | Tailored resistance to oils, chemicals, UV, abrasion, and flame |
| Conductor Sizes: 0.5 mm² – 400 mm² | From instrumentation to high‑amp power and welding applications |
| Class 5 & Class 6 Fine‑Strand Copper | Superior bend radii (as low as 6× OD); ideal for static and dynamic flex |
| Tinned‑Copper Conductor Option | Enhanced corrosion protection for maritime and wet‑area use |
| Flame‑Retardant & Halogen‑Free Jackets | Safe for indoor public spaces, shipboard, and offshore installations |
| Multi‑Core & Armoured Variants | Combine power and control; add steel braid or tape armour where needed |
| Custom Lengths & Pre‑Terminations | Factory‑assembly of plugs, boots, and glands to speed field deployment |
Our rubber insulated flexible cable solutions excel in the most demanding scenarios:
Portable Power & Welding Leads
SOOW‑style cables (300/500 V) and H07RN‑F (450/750 V) flex on reels, resist oil and slag, and maintain arc stability.
Industrial Automation
Robotic‑arm and cable‑carrier cables withstand continuous motion, oils, and temperature fluctuations in CNC cells and assembly lines.
Construction & Mining Equipment
Chloroprene‑jacketed power cables resist rock abrasion, hydraulic fluids, and UV in open‑pit and underground operations.
Entertainment & Events
Halogen‑free, flame‑retardant variants ensure low smoke and high safety for temporary power at concerts, broadcasts, and festivals.
Marine & Offshore Platforms
Tinned‑copper conductors and EPR jackets withstand salt spray, immersion, and UV exposure on ships, rigs, and floating terminals.
Agriculture & Irrigation
Flexible rubber cables power submersible pumps, conveyors, and field equipment—resisting fertilizers, mud, and UV.
“Switching to your rubber insulated flexible cable cut our maintenance calls by 60%. No more cracked sheaths on our cable reels.”
—Liam K., Plant Maintenance Manager
“Your pre‑terminated H07RN‑F assemblies saved our events crew days of prep time and eliminated wiring errors.”
—Marisol G., Production Manager, LiveStage Ltd.
Choosing the optimal rubber insulated flexible cable involves these key steps:
Define Voltage & Ampacity
Portable tools: 300/500 V, 16 AWG–12 AWG.
Welding leads: 600 V, 2 AWG–4/0 AWG for 200 A–500 A.
Heavy machinery: 600 V–1 kV, up to 400 mm² conductor sizes.
Select Jacket Compound
Natural Rubber (YZ/YC) for general‑purpose flexibility.
Chloroprene (YZW/YCW) or EPR for oil/chemical/ozone exposure.
TPE/XLPE for higher temperature endurance or specialized environments.
Determine Conductor Stranding Class
Class 5 for fixed or occasional flex.
Class 6 for continuous flex on reel or cable carrier.
Assess Mechanical Protection Needs
Unarmoured for indoor use.
Steel‑braid or tape armour under the sheath for direct burial or reel‑mounted reels.
Choose Safety Features
Flame‑Retardant for general installations.
Low‑Smoke Zero‑Halogen (LSZH) for confined or public spaces.
Specify Value‑Adds
Pre‑terminated plugs, boots, and strain‑relief glands.
Color‑coded jackets, printed legends, and batch traceability.
Our technical experts guide you through each criterion, ensuring your rubber insulated flexible cable specification matches real‑world demands.
Protect your investment and extend service life by following these guidelines:
Maintain Proper Bend Radii
Respect minimum static and dynamic bend radii (6×–8× cable diameter) to avoid conductor and sheath damage.
Use Certified Strain Relief
Install rated cable glands or clamps to prevent pull‑out stresses at terminations and connector interfaces.
Avoid Sharp Edges
When routing through panels or trays, employ bushings or grommets to guard against sheath cuts.
Secure & Support
Use UV‑resistant cable ties, clamps, and rollers for reel‑mounted runs to prevent abrasion and kinking.
Perform Pre‑Operational Tests
Conduct insulation‑resistance (megger) and continuity tests after installation and following any mechanical impact.
Schedule Routine Inspections
In dynamic or harsh environments, inspect jackets and conductors every 6–12 months—replace at first signs of wear.
Adhering to these best practices ensures your rubber insulated flexible cable installations remain problem‑free for years.
Decades of Elastomer Expertise
Since 1989, we’ve specialized in rubber cable compounding, extrusion, and assembly—delivering millions of meters worldwide.
Integrated Quality Assurance
ISO 9001 & ISO 14001 certified, our in‑house labs perform electrical, mechanical, and environmental testing to exceed industry standards.
Global Manufacturing & Local Support
Facilities in North America, Europe, and Asia ensure fast lead times and responsive field‑service teams in your region.
Custom Engineering Services
From bespoke jacket formulations to prototype runs and rapid over‑molded assemblies, our R&D team co‑develops solutions tailored to you.
Sustainability & Compliance
We offer PVC‑free and recyclable jacket options, run closed‑loop scrap recycling, and maintain full RoHS/REACH compliance.
When you partner with us, you gain a rubber insulated flexible cable expert committed to your success from design through commissioning—and beyond.
Initial Consultation
Share your application requirements—voltage, ampacity, environment, and assembly needs—and receive a tailored recommendation within 4 hours.
Detailed Proposal & Samples
Within 24 hours, get a customized quote, datasheets, and sample reels or pre‑terminated assemblies at nominal cost.
Approve & Schedule Production
Standard lead times: 3–7 business days for stocked configurations; 7–10 business days for custom compounds and assemblies.
Global Logistics
Choose CIF, DDP, or EXW shipping; track from factory dock to your site with real‑time updates.
Post‑Delivery Support
On‑site installation assistance, splicing services, and 24/7 technical hotline ensure smooth deployment and operation.
Our streamlined workflow delivers your rubber insulated flexible cable exactly when and where you need it—no surprises, just performance.
24/7 Technical Hotline
Field‑seasoned cable engineers are on call to answer specification, installation, and troubleshooting queries around the clock.
Comprehensive Warranty
We back every cable with a two‑year workmanship and materials warranty—defective cables replaced free of charge.
Preventive Maintenance Programs
Scheduled IR testing, mechanical inspections, and performance audits catch wear trends before failures occur.
Knowledge Center
Access whitepapers, installation videos, spec calculators, and best‑practice guides anytime via our online portal.
Don’t settle for generic cords that fail under pressure. Choose our proven rubber insulated flexible cable solutions—engineered for toughness, built for reliability, and backed by world‑class support.
Contact us today for a free consultation, custom spec sheet, and rapid quote—and experience the difference that premium rubber‑insulated flexibility brings to your operations.
