When you specify a belden access control cable you’re buying more than copper and plastic — you’re buying a finished solution designed to save installation time, reduce termination errors, and meet building-code demands. Belden’s access-control family is built around common project pain points: multiple signal types (card readers, lock power, REX, door contacts), routing through plenums and risers, and the need to terminate quickly and correctly on commissioning day. A well-chosen belden access control cable streamlines installation and reduces lifecycle headaches.
What “access control” cable families solve on site
A typical access-control run needs several things: power for an electric strike, low-voltage sensor/reader pairs, a request-to-exit contact, and often spare conductors for future expansions. Running separate single-core wires for each function is slow and error-prone. A belden access control cable bundles those conductors into a single assembly with cores printed or color-coded for “Lock Power,” “Card Reader,” and so on, which cuts pulling time and makes termination intuitive — particularly when Banana Peel® designs remove the need to strip an outer jacket. This is the kind of practical, time-saving detail that makes Belden a go-to brand for systems integrators.
(
Construction basics you should check on the datasheet
Not all access-control cables are equal. When you compare options, demand datasheet numbers, not photos:
conductor AWG/mm² and strand class (flex vs. fixed),
which cores are dedicated to lock power versus reader data,
whether the card-reader pairs are pair-twisted and shielded,
presence and type of overall screen (foil, braid) and drain conductor, and
jacket compound and fire rating (CMP, CMR, LSZH).
A proper belden access control cable datasheet lists these fields clearly so you can match part to duty without guesswork.
Shielding and EMI — when to pick screened pairs
Many access-control installations live in electrically noisy environments — near switchgear, HVAC drives, or lighting panels. If your card reader pairs run alongside power feeders or in long conduit runs, choose a screened belden access control cable with foil (or foil+braid) and a drain conductor. Shielding keeps data clean and prevents intermittent read failures that otherwise look like device faults. Belden’s product pages show screened reader pairs and identify which inner pairs carry sensitive signals — a useful filter when selecting between hundreds of SKUs.
Jacket chemistry and code compliance — mandatory checks
Because access-control cables often route through ceiling plenums and return-air spaces, the jacket chemistry is not an afterthought. Belden publishes CMP/CMP (plenum), CMR (riser), and LSZH (Flamarrest®/Eca) variants to meet regional codes. Always confirm the required fire/smoke ratings with your authority having jurisdiction and specify them in the RFQ. A correctly specified belden access control cable will save you from failed inspections and rework.
Banana Peel® and printed cores — small features that speed installs
Belden’s Banana Peel® constructions and application-printed jackets are not marketing fluff — they matter on site. With Banana Peel® you can remove the outer sheath quickly without damaging inner cores; printed identification on each sub-cable (e.g., “Lock Power,” “Card Reader”) reduces wiring mistakes. For a technician terminating dozens of doors in a new build, a belden access control cable with these features shaves hours off the labor estimate.
Typical part choices — match SKU to function
Belden’s catalog shows several common access-control SKUs: composite assemblies where 18 AWG lock power runs sit alongside 22 AWG reader pairs; variants with only reader pairs shielded; and heavy-duty versions for exterior or mechanical-risk locations. When your spec sheet lists exact part numbers, the installer gets the right cable the first time. Selecting the right belden access control cable up front prevents inconvenient substitutions during installation.
Termination best-practices for reliable doors
A cable is only as good as its termination. For belden access control cable runs:
label both ends with the cable part and door ID,
use ferrules on stranded lock power conductors to prevent strand splay,
fold-back and secure any shield/drain to a common earth point as recommended, and
follow manufacturer torque specs on terminal blocks for lock power and reader connections.
These practices prevent the “intermittent card read” calls that often trace back to poor crimps or floating shields.
RFQ checklist — what to demand from suppliers
To get apples-to-apples quotes include these fields in your RFQ for a belden access control cable:
exact conductor list (cores, AWG/mm²) and strand class,
which pairs are dedicated to readers vs locks,
shield details and drain conductor spec,
jacket compound and required fire rating (CMP/CMR/LSZH),
temperature rating and bend radius, and
packaging (spool/coil/cut-length) and sample policy.
Vendors that return full datasheets and part-specific test data are far easier to approve and deploy on large projects.
Installation tips that save commissioning time
Simple routing and handling discipline prevents many headaches:
avoid long parallel runs with high-current feeders (cross at right angles where unavoidable),
protect cable entries with grommets,
keep reader pairs away from fluorescent ballasts or large motors, and
don’t exceed published bend radii during pull-through.
Following these rules for a belden access control cable run keeps every door working reliably from day one.

Life-cycle value — why the right cable pays back
A modest premium for the correctly specified belden access control cable typically pays for itself in reduced labor, fewer service calls, and faster commissioning. Mistakes in shielding or jacket choice force change orders or re-pulls — direct costs far higher than the small upcharge for a spec-accurate cable. Choose parts that fit the environment and you minimize total cost of ownership.
When to choose composite vs discrete bundles
Composite access-control cables simplify pulls but can complicate replacement if one conductor group fails. For retrofit jobs where runs are short and access is easy, discrete bundled cables may be acceptable. For new construction, a composite belden access control cable with dedicated, labeled cores and Banana Peel® no-jacket options usually speeds installation and future troubleshooting.
Value-added options — extras that installers love
Consider these cost-effective upgrades when ordering belden access control cable in quantity:
tinned conductors or tinned braid for humid sites,
pre-printed footage or door IDs,
a few spare cores for future features, and
factory-cut and labeled convenience coils to match room drops.
These small specs reduce field time and make maintenance less error-prone.
