H07RN-F 1x70mm2 Rubber Cable

H07RN-F 1×70 is a single-core rubber-insulated flexible cable with a conductor cross-section of 70mm². H07RN-F 170mm² is constructed with a class 5 normal annealed copper core; EPR rubber insulation that withstands thermal fluctuations (-30°C to +60°C) and a robust black polychloroprene (PCP) jacket with excellent resistance to oils, abrasion and UV rays. H07RN-F 70mm² is suitable for heavy-duty applications requiring a robust single-phase power supply, as well as for cold and harsh industrial environments, such as providing mains power and connecting mobile equipment and appliances to arc welders, crushers or high-torque motors in manufacturing plants. The H07RN-F cable series is also available in various sizes such as H07RN-F 3-core, H07RN-F 4-core (3-phase + neutral) and H07RN-F 5-core for complex machinery with control circuits.

Product Features

• Resistant to chemicals, moisture and mechanical stresses

• Insulation maintains dielectric integrity at peak temperatures, preventing insulation breakdown under continuous use.

• Designed for frequent bending and movement, ideal for cranes, robotic arms or temporary movable grids.

• Complies with IEC 60245 for flame retardancy and low smoke emissions

Cable Construction

• Conductor: Plain Annealed Copper Class 5

• Insulation: EPR Rubber

• Sheath: PCP (Polychloroprene)

• Sheath Color: Black

H07RN-F Cable 70mm² Specification

• Temperature range: -30°C to +60°C

• Test Voltage: 2500V

• Nominal voltage: 450/750V

• Max. Temperature During Short Circuit (≤5S): 200°C

• Minimum Bending Radius: Fixed: 4 x overall diameter; Flexed: 6 x overall diameter

• Insulation Thickness (mm): 1.6

• Jacket Thickness(mm): 2.6

• Overall Diameter(mm): 17.8

• Nominal Weight(kg/km): 760
